Overview
Vapour Permeable Membrane
ULTRAPERM is Australia's industry-leading building membrane because it covers every base. Firstly, it is deemed-to-satisfy non-combustible in accordance with NCC 2022 Clause C2D10(6)(f) meaning it can be used in all building types. Secondly, it is classified as a 'Water Barrier' for weatherproofing compliance with NCC 2022 Clauses F3D3 and F8D3(1). Thirdly, it is rated 'Vapour Permeable, Class 4' meaning it can be used in all climate zones 1-8 in accordance with NCC 2022 Clauses F8P1 and F8D3(2). Finally, it also passes all AS 4200.1 testing with flying colours.
NCC 2022 Non-combustible
ULTRAPERM vapour permeable membrane is deemed-to-satisfy non-combustible in accordance with NCC 2022 Clause C2D10(6)(f) meaning it can be used on any building of types A, B and C construction.
AS 4200.1 Testing
ULTRAPERM vapour permeable membrane has been tested by NATA-accredited laboratories to all relevant Australian and International standards as required by AS 4200.1 and it has passed all criteria with flying colours.
Water Barrier
NCC 2022 Clauses F3D3 and F8D3(1) require all sarking-type material used for weatherproofing to comply with AS 4200.1 which includes being classified as a 'Water Barrier' when tested to AS 4201.4.
Vapour Permeable
ULTRAPERM vapour permeable membrane is classified 'Vapour Permeable Class 4' when tested to ASTM E96 as required by AS 4200.1 to comply with NCC 2022 Clauses F8P1 and F8D3(2) for all climate zones.
Extra Heavy Duty
AS 4200.1 requires membranes to be tested for edge-tear resistance in accordance with clause 5.3.2.3. ULTRAPERM vapour permeable membrane achieves the highest classification being 'Extra Heavy' duty.
Electrical Safety
ULTRAPERM vapour permeable membrane is electrically non-conductive when tested to AS 3100 as required by AS 4200.1 providing maximum electrical safety to builders and contractors on all projects.
Anti-glare Safety
The glare from reflective membranes can cause safety issues onsite as well as to traffic and neighbours. ULTRAPERM vapour permeable membrane is classified non-reflective when tested to AS 4201.5
Protects the Building
When installed as per AS 4200.2, ULTRAPERM vapour permeable membrane protects the building structure and insulation from the external elements during construction and through-out the life of the project.
Availability
Product Range
ULTRAPERM 511 Class 4 Membrane |
ULTRAPERM 531 Class 4 Membrane |
UPT5025 Membrane Tape |
Availability
Code |
Description |
Lead Time |
MOQ |
---|---|---|---|
UPS15030 | ULTRAPERM 511 Class 4 Membrane (Grey), 1.5 x 30m Roll | Stock | 1 Roll |
UPP15050 | ULTRAPERM 531 Class 4 Membrane (Blue), 1.5 x 50m Roll | Stock | 1 Roll |
Accessories
Code |
Description |
Lead Time |
MOQ |
---|---|---|---|
UPT5025 | TESA 50mm Membrane Joint Tape, 25m Roll | Stock | 1 Roll |
Technical Data
Test Item |
Standard |
Result |
---|---|---|
DTS Non-combustible - NCC 2022 | C2D10(6)(f) | Pass* |
Flammability Index | AS 1530.2 | 1* |
Material Thickness | Actual | <1mm* |
Dry Delamination | AS 4201.1 | Pass |
Wet Delamination | AS 4201.2 | Pass |
Shrinkage | AS 4201.3 | <0.1% |
Water Barrier | AS 4201.4 | Pass** |
Non Reflective | AS 4201.5 | Pass |
Vapour Permeability | ASTM E96 | Class 4*** |
Electrically Non Conductive | AS 3100 | Pass |
*ULTRAPERM is deemed-to-satisfy non-combustible as per NCC 2022 clause C2D10(6)(f), with thickness <1mm and Flammability Index <5. **ULTRAPERM is classified as a 'Water Barrier' as required by NCC 2022 Clauses F3D3 and F8D3(1). ***ULTRAPERM is classified as 'Vapour Permeable, Class 4' for use in all climate zones 1-8 as required by NCC 2022 Clauses F8P1 and F8D3(2).
Gallery
Downloads
Support
Customer Support
For same-day design assistance and technical support please contact our sales team directly on the below contact details. All our sales team and technical staff are locally based here in each timezone of Australia (AU) so we can provide the best possible service and support for your projects.
You can also request pricing or project-specific quotations using the below contact details. Please note, each of our email addresses is as per the following format and as set out below:
